CMX CP-120M Mini Mixer Amplifier | 120W Bluetooth PA Amplifier
The CMX CP-120M is a compact 120W mini mixer amplifier designed for public address systems, background music distribution, paging, and commercial audio installations. It supports Bluetooth streaming, USB/SD playback, FM radio, microphone inputs, and both 70V/100V and 4–8Ω speaker systems, making it suitable for offices, schools, restaurants, retail stores, mosques, and hospitality environments.
Key Features
◆ 120W RMS power output
◆ Supports 70V / 100V and 4–8Ω speaker systems
◆ Built-in Bluetooth wireless audio streaming
◆ USB and SD card MP3 playback
◆ Integrated FM radio tuner
◆ Echo effect for microphone and karaoke applications
◆ Compact desktop mixer amplifier design
◆ Multiple microphone and line inputs
◆ Bass, treble, and master volume controls
◆ LED indicators for signal, clip, protect, and power
◆ Short-circuit, overload, clip, and high-temperature protection
◆ AC and 24V DC dual power operation
◆ Suitable for commercial PA and background music systems
Technical Specifications
| Specification | Details |
|---|---|
| Model | CP-120M |
| Amplifier Type | Mini Mixer Amplifier |
| Rated Power Output | 120W |
| Speaker Outputs | 70V / 100V / 4–8Ω |
| Audio Sources | Bluetooth, USB, SD Card, FM Radio |
| Mic Inputs | 3 |
| Line Inputs | 2 |
| Mic1 Input | Balanced XLR with Phantom Power |
| Frequency Response | 60Hz – 15kHz |
| Signal-to-Noise Ratio | Line ≥85dB / Mic ≥72dB |
| THD | <0.5% |
| Power Supply | AC 110–240V & 24V DC |
| Dimensions | 320 × 210 × 90 mm |
| Weight | 4.9 kg |
Applications
◆ Public address systems
◆ Background music installations
◆ Schools and classrooms
◆ Retail stores and supermarkets
◆ Restaurants and cafés
◆ Mosques and prayer halls
◆ Hotels and hospitality venues
◆ Paging and announcement systems
◆ Small to medium commercial audio projects
Package Contents
◆ CMX CP-120M Amplifier
◆ Remote Control
◆ Power Cable
◆ User Manual
Additional Information
Brand: CMX Audio
Model: CP-120M
Type: Mini Mixer Amplifier
Official Product Page: CMX Audio Official Website
