CMX CP-60M Mini Mixer Amplifier | 60W Bluetooth PA Amplifier
The CMX CP-60M is a compact tabletop mini mixer amplifier designed for commercial audio systems, background music, and public address applications. It supports Bluetooth streaming, USB/SD playback, FM radio, microphone inputs, and both 70V/100V and 4–8Ω speaker systems, making it ideal for retail stores, cafés, schools, offices, and paging installations.
Key Features
◆ 60W RMS power output
◆ Supports 70V / 100V and 4–8 Ohm speaker systems
◆ Built-in Bluetooth wireless streaming
◆ USB and SD card MP3 playback
◆ Integrated FM radio tuner
◆ Echo effect function for microphone applications
◆ 2 microphone inputs
◆ 2 line inputs
◆ RCA line output
◆ Bass, treble, and master volume controls
◆ Front USB/SD multimedia player with display
◆ EMC and mute input for fire alarm integration
◆ Short-circuit, overload, clip, and high-temperature protection
◆ Compact tabletop installation design
◆ AC 230V and 12V DC power support
Technical Specifications
| Specification | Details |
|---|---|
| Model | CP-60M |
| Amplifier Type | Mini Mixer Amplifier |
| Rated Power Output | 60W RMS |
| Speaker Outputs | 70V / 100V / 4–8Ω |
| Audio Sources | Bluetooth, USB, SD Card, FM Radio |
| Mic Inputs | 2 |
| Line Inputs | 2 |
| Frequency Response | 60Hz – 15kHz |
| THD | <0.5% |
| Signal-to-Noise Ratio | Line ≥85dB / Mic ≥72dB |
| Phantom Power | +48V on Mic/Line2 |
| Power Supply | AC 230V / 12V DC |
| Dimensions | 220 × 200 × 72 mm |
| Weight | 2.6 kg |
Applications
◆ Retail stores
◆ Coffee shops and cafés
◆ Restaurants
◆ Schools and classrooms
◆ Mosques and prayer halls
◆ Small PA systems
◆ Background music systems
◆ Paging and announcement systems
Package Contents
◆ CMX CP-60M Amplifier
◆ Remote Control
◆ Power Cable
◆ User Manual
Additional Information
Brand: CMX Audio
Model: CP-60M
Type: Mini Mixer Amplifier
Official Product Page: CMX Audio Official Website
