Dahua 22" LM22-A200 @60Hz
Dahua 22" LM22-A200 @60Hz
Couldn't load pickup availability
Dahua 22" LM22-A200 @60Hz
The Dahua LM22-A200 is a 22-inch Full HD (1920×1080) monitor with a VA panel and LED backlight. It has HDMI and VGA inputs, a 60Hz typical refresh rate (75Hz maximum) and a slim-bezel plastic housing.
Full HD VA panel: The 1920×1080 resolution on a 22-inch screen gives sharp text and images for documents, browsing and video. The VA panel has a 3000:1 typical contrast ratio and shows 16.7 million colors (8-bit).
Wide 178° viewing angles: The picture stays readable from the side and from above or below (178° horizontal and vertical), which helps when more than one person is looking at the screen.
HDMI and VGA inputs: One HDMI input for modern computers, laptops and receivers, and one VGA input for older PCs. An HDMI cable is included in the box.
Anti-blue light and low power use: Dahua designed the monitor with an anti-blue-light function to reduce eye strain during long sessions. Typical power consumption is 30W, and 0.5W or less in standby.
Narrow bezel and VESA mount: The ultra-narrow side bezels (3.1 mm) keep the frame around the picture small. The 100×100 mm VESA mount lets you put the screen on a wall bracket or monitor arm instead of the included stand.
What's in the Box
Monitor, base (stand), power adapter, HDMI cable.
Good to know
The monitor is powered by an external 12V DC adapter (included). It has no DisplayPort input; the maximum refresh rate is 75Hz.
Technical Specifications
| Model | DHI-LM22-A200 |
| Screen Size | 22" |
| Panel Type | VA |
| Backlight | LED |
| Aspect Ratio | 16:9 |
| Resolution | 1920×1080 (FHD) |
| Brightness | 200 cd/m² |
| Contrast | 3000:1 (typical) |
| Display Colors | 16.7M (8-bit) |
| Viewing Angle (H/V) | 178° / 178° |
| Refresh Rate | 60Hz typical, 75Hz max |
| Inputs | 1 × HDMI, 1 × VGA |
| Power Supply | 12V DC (adapter) |
| Power Consumption | 30W typical, ≤0.5W standby |
| VESA Mount | 100 × 100 mm |
| Dimensions (without stand) | 496 × 285 × 51.5 mm |
| Bezel Width | 3.1 mm (left/right), 12.5 mm (bottom) |
| Operating Temperature | 0°C to 40°C |
| Certifications | CE, FCC |
📄 Datasheet: Download the official Dahua LM22-A200 datasheet (PDF)
