DSPPA 10W 8" Ceiling Round Loudspeaker | DSP8011
The DSPPA DSP8011 is a round in-ceiling and in-wall loudspeaker for 70 V and 100 V PA lines, taking 10 W on a 100 V line and 5 W on a 70 V line. It covers 60 Hz – 18 kHz, reaches a maximum sound pressure level of 104 ±2 dB and weighs 0.8 kg.
Works on 70 V and 100 V lines: The speaker has multiple terminals for a 70 V or 100 V PA system, so many speakers can be connected on one long cable run from the amplifier. DSPPA rates it at 5 W on 70 V and 10 W on 100 V.
Sound output: Sensitivity is 94 ±2 dB (1 W / 1 m) and the maximum sound pressure level is 104 ±2 dB at 1 m, with a frequency response from 60 Hz to 18 kHz. The speaker surround has a damping treatment for a long service life and clear sound.
Easy to install: A strong movable clip design holds the speaker in a Ø208–215 mm mounting hole, making installation simple.
Durable housing: The body is made of high-quality engineering plastic that DSPPA describes as durable, without deforming or fading.
Who it's for / Works with
The speaker connects to a PA amplifier with a 70 V or 100 V output.
Good to know
It needs a Ø208–215 mm mounting hole.
Technical Specifications
| Model | DSP8011 |
| Rated Power at 70 V | 5 W |
| Rated Power at 100 V | 10 W |
| Sensitivity (1 m, 1 W) | 94 ±2 dB |
| Max. SPL (1 m) | 104 ±2 dB |
| Frequency Response | 60 Hz – 18 kHz |
| Mounting Hole | Ø208 – 215 mm |
| Weight | 0.8 kg |
📄 Datasheet: Download the official DSPPA DSP8011 datasheet (PDF)
