Ezviz 4mp Outdoor Dual Lens Solar Camera | CB90Kit
Ezviz 4mp Outdoor Dual Lens Solar Camera | CB90Kit
Couldn't load pickup availability
Ezviz 4mp Outdoor Dual Lens Solar Camera/ CB90Kit
📦 EZVIZ CB90 Dual Kit — Dual-Lens All-Day Recording Wi-Fi Camera + Solar Panel 8W
Elevate your outdoor security with this all-in-one kit that delivers round-the-clock protection using dual lenses, intelligent detection, and solar-powered convenience.
🔍 Key Features
Dual 4MP lenses (top + bottom) let you see wide angles and detailed close-ups simultaneously
Long-range color night vision, or switch to IR mode for stealth viewing in darkness
Smart AI detection filters for humans and vehicles, reducing false alerts
Auto-tracking ability: when the top lens sees movement, the bottom lens will follow to zoom in
All-day recording using “AOV mode” (time-lapse during idle times, full video when motion is detected)
Large 10,400 mAh battery + included 8W solar panel for extended runtime without frequent recharging
Weatherproof (IP65) design, built for outdoor use in harsh environments
Micro-SD card support up to 512 GB, plus cloud storage option
Voice integration: works with Google Assistant & Amazon Alexa
Dual stream video, watermarking, privacy/security functions included
🔧 Technical Specifications
| Spec | Details |
|---|---|
| Image Sensors | Dual 1/3″ progressive scan CMOS, 4MP each |
| Lenses | Top: 2.8 mm @ F1.2 (Diagonally 110°, Horiz. 96° / Vert. 54°) • Bottom: 6 mm @ F1.2 (Diag. 60°, Horiz. 52°, Vert. 28°) |
| Pan/Tilt Range | Top lens: Pan 220°, Tilt 10° • Bottom lens: Pan 324°, Tilt 90° |
| Minimum Illumination | 0.01 Lux (with F1.2), 0 Lux with IR |
| Night Vision Distance | Up to 35 meters |
| Max Resolution & Frame Rate | 2K+ (2560 × 1440), up to 15 fps; self-adaptive under network conditions |
| Compression | H.265 / H.264 |
| Network / Wi-Fi | 2.4 GHz (802.11 b/g/n/ax), WPA-PSK / WPA2-PSK / WPA3, AP pairing |
| Battery | 10,400 mAh |
| Solar Panel | 8 W, Type-C cable, IP65 rated |
| Storage | microSD card (max 512 GB), CloudPlay support |
| Power Supply | DC 5 V / 2 A adapter (sold separately) |
| Operating Conditions | -20 °C to 50 °C, humidity ≤ 95% (non-condensing) |
| Weather-Proof Rating | IP65 |
| Dimensions (Camera) | 135 × 136.5 × 229.5 mm |
| Weight | Approx. 890g (camera), 428g (solar panel) |
🛠 What Comes in the Box
CB90 Dual camera unit
8 W solar panel + 3 m cable
Adjustable mounting bracket
Drill template & screw kit (2 screws)
Power cable
Quick Start Guide + regulatory info
🎯 Best Uses
Outdoor perimeter security (yard, driveway, entry gate)
Locations without easy power access thanks to solar support
Areas needing both wide surveillance and close-up monitoring (e.g. entrance + path)
Night-time protection in color mode (e.g. for property, storefronts)
