HIKVISION DS-TMG035 79GHz Entrance & Exit Radar

HIKVISION DS-TMG035 79GHz Entrance & Exit Radar

The Hikvision DS-TMG035 is an entrance and exit radar for barrier gates, built around a 79 GHz MMIC. It detects vehicles to trigger the barrier gate, and it detects vehicles and pedestrians to stop the boom pole from falling while they are passing. Detection distance and width are adjustable, and no learning is needed.

Direction Recognition: The radar recognises the moving direction of the target, so it can be used where entrance and exit traffic is mixed.

Anti-Fall Protection: Signal processing detects pedestrians and vehicles stably and prevents the boom pole of the barrier gate from falling while they are passing.

Adjustable Detection: The trigger distance is adjustable up to 6 m and the detection width from 0 to 2 m. It can also distinguish a following vehicle at 0.5 to 2 m (adjustable).

No Learning Needed: The radar works without a learning process, which Hikvision says makes it suitable for more complex environments. Installation and maintenance need little manual work.

RS-485 or Wi-Fi: The radar communicates over RS-485 or Wi-Fi. The Wi-Fi version has a mobile phone app for debugging and upgrading.

Status LEDs and Memory: LED indicators show the working status. The radar saves its configuration automatically and restores it after a power cut and reboot.

Good to know

Hikvision states that detection is not affected by electromagnetic interference, lighting, dust, rain or snow.

Power is 9 to 12 VDC, under 0.25 A (under 3 W).

The barrier gate is not included.

Technical Specifications

📄 Datasheet: Download the official Hikvision DS-TMG035 datasheet (PDF)
