Hikvision Wireless Outdoor PIR Curtain Detector with Anti-Masking | DS-PDC10AM-EG2-WB
The Hikvision DS-PDC10AM-EG2-WB is a slim wireless PIR curtain detector with anti-masking for the Hikvision AX PRO alarm system. Its IP65 design suits window frames, walls and outdoor perimeter installation.
Key Features:
Curtain Detection: PIR curtain detection up to 10 m on a wall or 5 m on a ceiling.
Anti-Masking: Active anti-masking against attempts to block the detector.
IP65 Outdoor Design: IP65 protection and -25 °C to 60 °C operating temperature.
Pet Immunity: Pet immunity up to 12 kg (wall mount).
Long-Range Wireless: Two-way 433 MHz Tri-X wireless with up to 1 km range in open space and up to 5 years battery life.
Tamper Protection: Front and rear tamper protection.
Technical Specifications:
| Model | DS-PDC10AM-EG2-WB |
| Detection type | Passive infrared (PIR) curtain with anti-masking |
| Detection range | 10 m wall mount / 5 m ceiling mount |
| Pet immunity | Up to 12 kg (wall mount only) |
| Mounting height | 2 to 3.5 m |
| Wireless frequency | 433 MHz (WB model), two-way Tri-X |
| RF range (free space) | 1 km |
| Battery | 2 x CR123A |
| Standby battery life | Up to 5 years |
| Ingress protection | IP65 |
| Operating temperature | -25 °C to 60 °C |
| Operating humidity | 10% to 90% |
| Dimensions (W x H x D) | 29.2 x 134.4 x 39.5 mm |
| Weight | 118.5 g |
| Tamper protection | Front and rear |
| Installation | Wall or ceiling, with L-shaped bracket adapter |
Compatibility: Works with the Hikvision AX PRO wireless alarm system (control panel sold separately).
