Hikvision Wireless Receiver Expander 433 MHz | DS-PM1-RT-HWB
The Hikvision DS-PM1-RT-HWB is a 433 MHz Tri-X wireless receiver that adds wireless capability to the Hikvision AX Hybrid PRO wired control panel, so Hikvision Tri-X wireless detectors can join the system.
Key Features:
Wireless Expansion: Expands the wireless capability of an AX Hybrid PRO control panel; Hikvision Tri-X detectors are added to the panel through it.
Up to 32 Wireless Detectors: Supports up to 32 wireless detectors (portable emergency button not included).
Long Range: 433 MHz receiver with up to 1300 m wireless transmission distance.
Secure Wireless: Frequency hopping and 128-bit AES encryption.
Technical Specifications:
| Model | DS-PM1-RT-HWB |
| RF frequency | 433 MHz |
| Wireless transmission distance | Up to 1300 m |
| Wireless security | Frequency hopping, 128-bit AES encryption |
| Wireless detector capacity | Up to 32 wireless detectors (portable emergency button not included) |
| Bus | 1 Speed-X bus |
| Maximum current | 100 mA @ 12 VDC |
| Quiescent current | 40 mA @ 12 VDC |
| LED indicators | Green: power / find me; Orange: alarm / fault |
| Dimensions (W x H x D) | 110 x 155 x 32 mm |
| Shell material | Plastic |
| Weight | 233 g |
| Operating temperature | -10 °C to 40 °C |
| Operating humidity | 10% to 90% |
Compatibility: Works with the Hikvision AX Hybrid PRO alarm control panel and Hikvision Tri-X 433 MHz (-WB) wireless devices.
📄 Datasheet: Download the official Hikvision DS-PM1-RT-HWB datasheet (PDF)
