Tenda 5-Port Desktop Switch with 4-Port PoE | TEF1105P-4-63W

Tenda 5-Port Desktop Switch with 4-Port PoE | TEF1105P-4-63W

The Tenda TEF1105P-4-63W is a 5-port 10/100 Mbps desktop PoE switch: ports 1–4 power and connect IP cameras or access points, and port 5 is the uplink to your NVR or router. Each PoE port gives up to 30 W with a 58 W total PoE output, and the Extend mode carries power and data up to 250 m.

4 PoE ports: Ports 1–4 follow IEEE 802.3af (15.4 W) and IEEE 802.3at (30 W). A camera or access point gets power and data over one network cable, so no power socket is needed where it is mounted.

58 W PoE output: The whole switch can deliver up to 58 W of PoE power, shared by the four PoE ports. Add up your devices' power before connecting them.

Extend mode up to 250 m: In Standard mode the switch works like a normal unmanaged switch. When Extend mode is turned on, power and data can reach up to 250 m at 10 Mbps, which can replace an extender for a far-away camera.

6 kV lightning protection: The ports are protected against surges up to 6 kV, which matters for cameras installed outdoors or high on buildings.

Who it's for / Works with

Small surveillance and Wi-Fi setups with up to four PoE IP cameras or access points (IEEE 802.3af/at).

Good to know

All ports run at 10/100 Mbps, not Gigabit. In Extend mode the PoE ports work at 10 Mbps. It is unmanaged, with no web interface. The "63W" in the model name is not the PoE budget: the PoE ports share 58 W.

Technical Specifications
