TP-Link JetStream 16-Port Gigabit Easy Smart PoE Switch with 8-Port PoE+, 150W | TL-SG1016PE
The TP-Link TL-SG1016PE is a 16-port Gigabit Easy Smart switch for desktop or 13-inch rack installation. Eight of its ports (1–8) are 802.3af/at PoE+ ports that send data and power over one Ethernet cable, with up to 30 W per port and a 150 W total PoE budget*, so it can power access points, IP cameras and IP phones without separate adapters.
16 Gigabit Ports with 8× PoE+: All 16 RJ45 ports run at 10/100/1000 Mbps with auto-negotiation and Auto MDI/MDIX. Ports 1–8 add PoE+ output, while ports 9–16 serve regular wired devices such as PCs, printers and NVRs.
Port Priority and PoE Auto Recovery: When the total PoE draw reaches 150 W, the switch cuts power to the lowest-priority port (port 1 has the highest priority) to protect the system. PoE Auto Recovery automatically reboots powered devices that drop offline or stop responding.
Easy Smart Management: A web-based interface and the Easy Smart Configuration Utility give you QoS (port-based, 802.1p and DSCP with 4 priority queues), up to 32 VLANs, IGMP Snooping, static link aggregation, port mirroring, cable diagnostics and loop prevention.
Fanless Metal Case: The steel case is 1U high and fanless, so the switch runs silently in offices and other noise-sensitive places.
Who it's for / Works with: Small offices and surveillance setups that need 8 powered ports for IP cameras, access points or IP phones plus 8 more Gigabit ports for other devices.
Good to know: Only ports 1–8 supply PoE; the 150 W budget is shared between them. The configuration utility runs on Microsoft Windows; the web interface works from a browser. There are no SFP ports.
Technical Specifications
| Specification | TP-Link TL-SG1016PE |
|---|---|
| Interface | 16× 10/100/1000 Mbps RJ45 ports, Auto-Negotiation / Auto MDI/MDIX |
| PoE ports | Ports 1–8, IEEE 802.3af/at (PoE+), up to 30 W per port |
| Total PoE budget | 150 W* |
| Standards | IEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p |
| Switching capacity | 32 Gbps |
| Forwarding rate | 23.8 Mpps |
| MAC address table | 8K |
| Packet buffer | 4.1 Mbit |
| Jumbo frame | 10 KB |
| QoS | Port-based / 802.1p / DSCP priority, 4 priority queues, rate limit, storm control |
| L2 features | IGMP Snooping v1/v2/v3, static link aggregation, port mirroring, cable diagnostics, loop prevention |
| VLAN | Up to 32 VLANs (out of 4K VLAN IDs), MTU / Port / Tag VLAN |
| PoE features | PoE management, Extend Mode, PoE Auto Recovery |
| Management | Web-based GUI, Easy Smart Configuration Utility (Windows) |
| Power supply | 100–240 V AC, 50/60 Hz (internal, power cord) |
| Max. power consumption | 13.07 W (no PD); 173.88 W (with 150 W PD), 220 V/50 Hz |
| Fan | Fanless |
| Mounting | Desktop / 13-inch rack mount, 1U steel case |
| Dimensions (W×D×H) | 294 × 180 × 44 mm |
| Operating temperature | 0–45 °C |
| Certification | FCC, CE |
* PoE budget figures are based on TP-Link laboratory testing; the actual PoE budget is not guaranteed and varies with the connected devices and the environment.
📄 Datasheet: Download the official TP-Link TL-SG1016PE datasheet (PDF)
