TP-Link 300Mbps Wireless AV600 Powerline Extender Starter Kit | TL-WPA4220 kit

◆ One Touch Super Range Extension - Wi-Fi Clone Button simplifies your Wi-Fi configuration and helps build a seamless unified home network

◆ HomePlug AV standard compliant

◆ Extend 300Mbps wireless connections to previously hard-to-reach areas of your home and office*

TP-Link TL-WPA4220KIT Specifications:

AV600 Powerline Wi-Fi Kit

━━━━━━━━━━━━━━━━━━

Powerline Performance

Powerline Speed: Up to 600Mbps
Range: Up to 300 meters over electrical wiring
Modulation Technology: OFDM (PLC)
Powerline Security: 128-bit AES Encryption
Compatibility: Compatible with all HomePlug AV & AV2 standard powerline adapters
Standards & Protocols: HomePlug AV, IEEE 802.3, IEEE 802.3u

Ethernet Speed: 10/100Mbps

━━━━━━━━━━━━━━━━━━

Wireless Performance (TL-WPA4220)

Frequency: 2.4 – 2.4835GHz
Speed:
Up to 300Mbps (802.11n)
Up to 54Mbps (802.11g)
Up to 11Mbps (802.11b)

Transmission Power:
CE: <20dBm (2.4GHz)
FCC: <30dBm

Reception Sensitivity:
270M: -68dBm @10% PER
130M: -68dBm @10% PER
108M: -68dBm @10% PER
54M: -68dBm @10% PER
11M: -85dBm @8% PER
6M: -88dBm @10% PER
1M: -90dBm @8% PER

Wireless Security:
64/128-bit WEP
WPA / WPA2
WPA-PSK / WPA2-PSK

Advanced Functions:
Enable/Disable Wireless Radio
WMM
Wireless Statistics

━━━━━━━━━━━━━━━━━━

Hardware Features

Plug Type: EU / UK / US / AR
Interfaces: 2 × 10/100Mbps Ethernet Ports
Buttons: Pair, Reset, Wi-Fi / Wi-Fi Clone
LED Indicators: PWR, PLC, ETH, Wi-Fi / Wi-Fi Clone
Power Consumption (220V/50Hz):
Maximum: 7.608W
Typical: 7.216W
Standby: 4.610W
Dimensions: 94 × 54 × 40 mm

━━━━━━━━━━━━━━━━━━

Software & Management

Management: TP-Link tpPLC App or tpPLC Utility (PC)

━━━━━━━━━━━━━━━━━━

Package Contents

TL-WPA4220 Powerline Wi-Fi Adapter
TL-PA4010 Powerline Adapter
1 × Ethernet Cable (2m RJ45)
Resource CD
Quick Installation Guide

━━━━━━━━━━━━━━━━━━

Certifications

CE, FCC, RoHS

━━━━━━━━━━━━━━━━━━

System Requirements

Windows 2000 / XP / 2003 / Vista / 7 / 8
Mac OS
Linux

━━━━━━━━━━━━━━━━━━

Environmental Conditions

Operating Temperature: 0°C – 40°C
Storage Temperature: -40°C – 70°C
Operating Humidity: 10% – 90% Non-Condensing
Storage Humidity: 5% – 90% Non-Condensing

The theoretical maximum channel data transfer rate is derived from HomePlug AV specifications. Actual data transfer rate will vary from network environment including: distance, network traffic, noise on electrical wires, building material and construction, quality of electrical installation and other adverse conditions.
