TP-Link TL-WR941HP 450Mbps | High Power Wireless Router

TP-Link TL-WR941HP 450Mbps | High Power Wireless Router

Superior Range: High power amplifiers and high-gain antennas provide enhanced wireless range.

Wall-Penetrating Wi-Fi: Enhanced Wi-Fi signal cuts through walls and obstacles, eliminating dead zones

3 Modes Functionality: Offers three wireless modes, including Router, Range Extender, and Access Point

450Mbps Wireless Speed: Ideal for video streaming, online gaming and VoIP

TP-Link TL-WR941HP – N450 High-Power Wi-Fi 4 Router

Wireless

Standards & Protocols

◆ Wi-Fi 4 (802.11n)
◆ IEEE 802.11n/b/g – 2.4 GHz

Wi-Fi Speeds

◆ 2.4 GHz: 450 Mbps (N450)

Coverage

◆ Suitable for 4 Bedroom Houses
◆ 3× Detachable 9 dBi High-Gain Antennas
◆ High-Power FEM for stronger signal coverage

Capacity & Modes

◆ Legacy Wi-Fi Capacity
◆ Working Modes:
– Router Mode
– Access Point Mode
– Range Extender Mode

Security

◆ SPI Firewall
◆ Access Control
◆ IP & MAC Binding
◆ Application Layer Gateway
◆ 1× 2.4 GHz Guest Network
◆ VPN Server: OpenVPN / PPTP
◆ Wi-Fi Encryption: WEP / WPA / WPA2 / WPA/WPA2-Enterprise (802.1x)

Hardware

◆ Processor: Single-Core CPU
◆ 1× 10/100 Mbps WAN Port
◆ 4× 10/100 Mbps LAN Ports
◆ Buttons:
– Wi-Fi On/Off
– Power On/Off
– WPS
– Reset
◆ Power: 12V ⎓ 1.5A

Software

Protocols

◆ IPv4 / IPv6

Parental Controls

◆ URL Filtering
◆ Time Controls

WAN Types

◆ Dynamic IP
◆ Static IP
◆ PPPoE
◆ PPTP
◆ L2TP

QoS

◆ QoS by Device

NAT Forwarding

◆ Virtual Server
◆ Port Forwarding
◆ Port Triggering
◆ DMZ
◆ UPnP

IPTV

◆ IGMP Proxy
◆ IGMP Snooping

DHCP

◆ Server
◆ Address Reservation
◆ DHCP Client List

DDNS

◆ NO-IP
◆ DynDNS

Management

◆ Tether App
◆ Web Interface

Test Data

Transmission Power

◆ CE: <20 dBm (2.4 GHz)
◆ FCC: <30 dBm

Reception Sensitivity

◆ 450 Mbps: -71 dBm @10% PER
◆ 130 Mbps: -74 dBm @10% PER
◆ 108 Mbps: -74 dBm @10% PER
◆ 54 Mbps: -77 dBm @10% PER
◆ 11 Mbps: -91 dBm @8% PER
◆ 6 Mbps: -89 dBm @10% PER
◆ 1 Mbps: -97 dBm @8% PER

Physical

◆ Dimensions: 227.5 × 190 × 48.3 mm
◆ Operating Temperature: 0°C ~ 40°C
◆ Storage Temperature: -40°C ~ 70°C
◆ Operating Humidity: 10% ~ 90% Non-Condensing
◆ Storage Humidity: 5% ~ 90% Non-Condensing
◆ Certifications: FCC, CE, RoHS

Package Contents

◆ TL-WR941HP Router
◆ Power Adapter
◆ RJ45 Ethernet Cable
◆ Quick Installation Guide
