TP-Link 5G AX3000 Dual-Band Wi-Fi 6 Gigabit Router with SIM Slot | Archer NX505
The TP-Link Archer NX505 is an indoor 5G router: insert a Nano SIM card and it shares a 5G connection of up to 6.47 Gbps download (4G LTE up to 2 Gbps) over AX3000 dual-band Wi-Fi 6 and Gigabit Ethernet ports. It has six internal 5G/LTE antennas plus two TS-9 connectors for optional external antennas, and a Gigabit WAN/LAN port for a cable, fiber or DSL modem.
Color: White
Key Features
5G with 4G fallback: Supports 5G NR (up to 6.47 Gbps down / 1.25 Gbps up), 4G LTE (up to 2 Gbps / 211 Mbps) and 3G, so it keeps working where 5G is not available.
SIM plug & play: Insert an activated Nano SIM and power on to get online, with no fixed line needed — useful for homes, offices, shops and farms without a cable line.
AX3000 Wi-Fi 6: Dual-band Wi-Fi 6 at 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz). TP-Link states the router handles 200+ wireless devices.
Gigabit WAN/LAN with backup: 2× Gigabit LAN ports plus 1× Gigabit WAN/LAN port. Connect a fiber or DSL modem to use it as a normal Wi-Fi router, with the 5G/LTE connection acting as a backup.
EasyMesh, VPN and Tether app: Expand coverage with EasyMesh-compatible extenders and routers, run a PPTP, IPSec or OpenVPN server, set parental controls and guest Wi-Fi, and manage it from the Tether app or a web browser.
Who it's for / Works with
Homes and small offices that want fast mobile internet from a SIM card, or a fixed line with automatic 5G/4G backup. Works with cable, fiber and DSL modems through the WAN/LAN port and with EasyMesh devices.
Good to know
- A SIM card and data plan are not included. The SIM must be activated and without a PIN lock. Check that your operator uses one of the supported bands below; actual bands may vary slightly by region.
- Mobile speeds are maximum values and depend on coverage, plan and network load. Wi-Fi rates are maximum physical rates.
- Indoor use only. External antennas are optional and not included.
What's in the Box
◆ Archer NX505 router
◆ RJ45 Ethernet cable
◆ Power adapter
◆ Quick Installation Guide
Technical Specifications
| Specification | Archer NX505 |
|---|---|
| 5G NR Bands | N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N71/N75/N76/N77/N78 |
| 4G LTE Bands | FDD: B1/B3/B5/B7/B8/B20/B28/B32/B71; TDD: B38/B40/B41/B42/B43 |
| 3G Bands | DC-HSDPA/HSPA+/HSPA/UMTS: B1/B3/B5/B8 |
| Mobile Speed | 5G: 6.47 Gbps down / 1.25 Gbps up; 4G LTE: 2 Gbps down / 211 Mbps up |
| SIM | 1× Nano SIM slot |
| Wi-Fi Standard | IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz |
| Wi-Fi Speeds | 2402 Mbps at 5 GHz, 574 Mbps at 2.4 GHz (AX3000) |
| Antennas | 3× internal Wi-Fi, 6× internal NR/LTE; 2× TS-9 ports for external 5G/4G antennas |
| Ethernet Ports | 2× Gigabit LAN, 1× Gigabit WAN/LAN |
| Buttons | Wi-Fi/WPS, Reset, Power |
| Power | 12 V / 2.5 A |
| Wi-Fi Security | WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3 |
| Operating Modes | 3G/4G/5G Router, Wireless Router |
| WAN Types | Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| VPN Server | PPTP, IPSec, OpenVPN |
| Guest Network | 1× 2.4 GHz, 1× 5 GHz |
| Protocols | IPv4, IPv6 |
| Dimensions | 99 × 99 × 190 mm |
| Operating Temperature | 0 °C – 40 °C |
📄 Datasheet: Download the official TP-Link Archer NX505 datasheet (PDF)
