Tp-Link Archer MR505 | 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

Tp-Link Archer MR505 | 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

Description:

Supports 4G+ Cat6 with download speeds up to 300 Mbps for fast, reliable internet anywhere.

Insert SIM and go – no configuration required, tested for compatibility in over 100 countries.

Features MU-MIMO technology for better Wi-Fi efficiency and simultaneous data streaming.

EasyMesh-compatible, allowing seamless expansion into a whole-home mesh Wi-Fi system.

Delivers strong, stable signal to all your connected devices.

Includes full Gigabit ports for high-speed wired connections – ideal for gaming and IPTV.

Wi-Fi Router Mode: use Ethernet as a backup if 4G isn’t available.

Quick setup and control via the TP-Link Tether app.

Hardware Features

Wireless Features

Wireless Standards	IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency	2.4 GHz and 5 GHz
Signal Rate	300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
Reception Sensitivity	5 GHz: 11a 54M: -77 dBm 11ac HT20: -73 dBm 11ac HT40: -68 dBm 11ac HT80 : -64 dBm 11n HT20: -77 dBm 11n HT40: -73 dBm 2.4 GHz: 11g 54M: -74 dBm 11n HT20: -72 dBm 11n HT40: -69 dBm
Transmit Power	< 20 dBm (2.4 GHz), < 23 dBm (5 GHz)
Wireless Functions	Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
WAN Failover	Yes
Wireless Security	64/128-bit WEP, WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
Network Type	Compatible with the majority of mobile operators and supports 4G/3G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz) DC-HSPA+/HSPA/UMTS: B1/B3/B5/B8 (2100/850/900 MHz)

Software Features

Quality of Service	Prioritizes network traffic by device
Security	DoS, IPv4 SPI Firewall, IPv6 Firewall, IP and MAC Address Binding, Access Control, Service Filtering
WAN Type	Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
Management	TP-Link Cloud, Local Management, Remote Management
DHCP	Server, DHCP Client List, Address Reservation
Port Forwarding	ALG, Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS	TP-Link, DynDns, NO-IP
VPN	VPN Server: PPTP VPN, OpenVPN
Parental Controls	URL Filtering, Time Controls
Protocols	IPv4, IPv6
Guest Network	2.4 GHz Guest Network x 1, 5 GHz Guest Network x 1

Others

Certification	CE, RoHS
Package Contents	4G+ Cat6 300 Mbps LTE AC1200 Wireless Dual Band Gigabit Router Archer MR505 1.5m Power Adapter RJ45 Ethernet Cable Quick Installation Guide
Environment	Operating Temperature: 0℃~40℃ (32℉ ~104℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
