CMX EA-60T 2-Zone Mixer Amplifier | 60W Bluetooth PA Amplifier
The CMX EA-60T is a compact 2-zone mixer amplifier designed for professional public address and background music systems. Featuring independent zone control, Bluetooth streaming, USB/SD MP3 playback, FM radio, microphone inputs, and support for both high-impedance and low-impedance speaker systems, the EA-60T is ideal for schools, offices, restaurants, retail stores, mosques, and commercial audio installations.
Key Features
◆ 60W RMS power output
◆ 2 independent speaker zones with separate controls
◆ Built-in Bluetooth wireless audio streaming
◆ USB and SD card MP3 playback
◆ Integrated FM radio tuner
◆ Supports 70V / 100V and 4Ω / 8Ω / 16Ω speaker systems
◆ Front-panel LCD display with playback controls
◆ Multiple microphone and line inputs
◆ Telephone paging input with VOX priority
◆ Bass, treble, and master volume controls
◆ Mic 1 balanced XLR input with phantom power
◆ RCA input and RCA output connections
◆ LED indicators for power, signal, clip, and protection
◆ Protection against short circuit, overload, clipping, and overheating
◆ AC and 24V DC dual power operation
◆ Compact tabletop installation design
Technical Specifications
| Specification | Details |
|---|---|
| Model | EA-60T |
| Amplifier Type | 2-Zone Mixer Amplifier |
| Rated Power Output | 60W |
| Zones | 2 Zones |
| Speaker Outputs | 70V / 100V / 4Ω / 8Ω / 16Ω |
| Audio Sources | Bluetooth, USB, SD Card, FM Radio |
| Mic Inputs | 3 |
| Line Inputs | 2 |
| Telephone Input | Yes |
| Mic 1 Connector | Balanced XLR with Phantom Power |
| Frequency Response | 60Hz – 15kHz |
| Protection | Short Circuit, Overload, Overheat, Clip |
| Power Supply | AC 110–240V & 24V DC |
| Installation Type | Tabletop / Desktop |
Applications
◆ Public address systems
◆ Background music systems
◆ Schools and classrooms
◆ Retail stores and supermarkets
◆ Restaurants and cafés
◆ Mosques and prayer halls
◆ Offices and commercial buildings
◆ Paging and announcement systems
◆ Multi-zone audio installations
Package Contents
◆ CMX EA-60T Mixer Amplifier
◆ Remote Control
◆ Power Cable
◆ User Manual
Additional Information
Brand: CMX Audio
Model: EA-60T
Type: 2-Zone Mixer Amplifier
Official Product Series: CMX Audio
