Hikvision 80W 2-Zone Network Amplifier with FM Radio | DS-QAE1A80G1-VB/ST
The Hikvision DS-QAE1A80G1-VB/ST is an 80 W, 2-zone network amplifier with FM radio support. It connects to your network over RJ45, supports scheduled and real-time broadcasts and text-to-speech in 8 languages, and plays audio from Bluetooth, USB, a microphone, RCA line sources or FM radio.
Color: White
Key Features:
FM radio: The amplifier can play FM radio when an external FM antenna is connected, adding live radio as an audio source alongside your own music and announcements.
Network audio with scheduling: Real-time and scheduled tasks, resume play and an audio material library are supported, with 4 GB of built-in eMMC storage (1 GB for audio files). Music and announcements can play automatically at set times.
Text-to-speech in 8 languages: Type a message and broadcast it with text-to-speech in English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean or French, with male and female voice options.
Alarm linkage: With 1 alarm input and 1 alarm output plus arming schedules, an alarm event can trigger an audio broadcast automatically.
Two zones with separate volume: Two 100 V constant-voltage outputs feed two speaker zones with their own volume knobs, plus an independent microphone volume control and two-channel mixing output. Up to 3 amplifiers can be cascaded over RCA.
Good to know: FM radio works only with an FM antenna, which is purchased separately. Speakers and microphone are not included. The unit runs on 24 V DC.
Technical Specifications:
| Model | DS-QAE1A80G1-VB/ST |
| Type | Network amplifier, 2 zones |
| Rated Power | 80 W |
| Frequency Response | 80 Hz to 20 kHz (±3 dB) |
| THD / SNR | ≤ 1% / ≥ 100 dB |
| Audio Bit Rate | G.711 μ-law / G.711 A-law (64 Kbps), MP3 (128 Kbps) |
| Speech Synthesis | English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French |
| Network | 1 × RJ45 10/100 Mbps Ethernet port |
| Interface Protocols | ISAPI, ISUP, RTP |
| Network Protocols | IPv4, HTTP, HTTPS, SSL/TLS, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH |
| Audio Inputs | Bluetooth, USB 2.0, 6.35 mm microphone jack, RCA in 1–2, FM radio (external antenna) |
| Audio Outputs | 2 × 100 V constant voltage, RCA out 1–2 |
| Cascading | Up to 3 amplifiers via RCA |
| Alarm | 1 input, 1 output |
| Local Storage | 4 GB eMMC (1 GB for audio files) |
| USB | USB 2.0/3.0 flash drives, FAT32, up to 128 GB |
| Protection | Short circuit, overcurrent, over-temperature, anti-static, electric shock |
| Power Supply | 24 V DC |
| Material | Plastic |
| Color | White |
| Dimensions | 190.8 × 230.8 × 51.2 mm |
| Weight | Approx. 1496.2 g |
| Operating Temperature | -10 °C to 55 °C |
| Operating Humidity | < 90% (no condensation) |
📄 Datasheet: Download the official Hikvision DS-QAE1A80G1-VB/ST datasheet (PDF)
