TP-Link EAP725-Outdoor Omada 7 Outdoor BE5000 Wi-Fi 7 Access Point
TP-Link EAP725-Outdoor Omada 7 Outdoor BE5000 Wi-Fi 7 Access Point
تعذر تحميل توفر الاستلام
TP-Link EAP725-Outdoor Omada 7 Outdoor BE5000 Wi-Fi 7 Access Point
Product Description
The TP-Link EAP725-Outdoor is a high-performance outdoor Wi-Fi 7 BE5000 Access Point designed for reliable, high-speed wireless coverage in outdoor environments. It delivers up to 5 Gbps combined wireless throughput, with 4-stream dual-band Wi-Fi 7, a 2.5Gbps Ethernet port, and flexible antenna configurations for both wide-area and focused directional coverage.
Its unique antenna system allows switching between built-in directional antennas and detachable omnidirectional antennas, making it suitable for different outdoor deployment scenarios such as farms, parking areas, resorts, campuses, warehouses, and outdoor commercial spaces.
The EAP725-Outdoor is built for harsh outdoor conditions with an IP66 weatherproof enclosure, 6kV lightning protection, and an operating temperature range of -30°C to 70°C.
Key Features
- Wi-Fi 7 BE5000 dual-band outdoor access point
- Up to 5.0 Gbps combined wireless speed
- 4-stream Wi-Fi 7
- 5 GHz: up to 4324 Mbps
- 2.4 GHz: up to 688 Mbps
- 1 × 2.5Gbps Gigabit Ethernet port
- 802.3at PoE+ powered
- Maximum power consumption: 18.4W
- Switchable Directional / Omnidirectional antenna modes
- Built-in directional antennas
- Detachable external omnidirectional antennas
- Automatic external antenna detection
- IP66 weatherproof enclosure
- 6kV lightning protection
- Operating temperature: -30°C to 70°C
- Omada Mesh & Seamless Roaming
- Centralized Omada cloud and controller management
- MLO, 4K-QAM, OFDMA and Beamforming
- Pole and wall mounting kits included
Technical Specifications
| Specification | Details |
|---|---|
| Model | EAP725-Outdoor |
| Wi-Fi Standard | Wi-Fi 7 (IEEE 802.11be) |
| Wireless Class | BE5000 |
| 2.4 GHz Speed | 688 Mbps |
| 5 GHz Speed | 4324 Mbps |
| Total Wireless Speed | Up to 5.0 Gbps |
| Streams | 4-Stream |
| Ethernet | 1 × 10/100/1000/2500 Mbps RJ45 |
| PoE | 802.3at PoE+ |
| Max. Power Consumption | 18.4W |
| Antennas – 2.4 GHz | 2 × 4.5 dBi external Omni / 2 × 8.3 dBi internal Directional |
| Antennas – 5 GHz | 2 × 5.3 dBi external Omni / 2 × 13.2 dBi internal Directional |
| Bluetooth | BLE 5.2 |
| Weather Protection | IP66 |
| Lightning Protection | 6kV |
| Operating Temperature | -30°C to 70°C |
| Mounting | Pole / Wall |
| Management | Omada App, Cloud, Hardware & Software Controller |
| Mesh | Omada Mesh |
| Roaming | Seamless Roaming 802.11k/v/r |
| Security | WPA/WPA2/WPA3, 802.1X, Captive Portal |
| Dimensions | 208 × 160 × 55 mm |
| Weight | 1.33 kg |
Specifications verified against TP-Link's official product page.
What's in the Box
- TP-Link EAP725-Outdoor Access Point
- Detachable Omnidirectional Antennas
- Mounting Kit
- Installation Guide
Recommended Coverage
- Omnidirectional: approximately 300 m² / 3,229 ft²
- Directional: approximately 510 m² / 5,500 ft²
Actual coverage varies depending on environment, obstacles, client devices, interference, and network conditions.
