Zigbee Smart Plug with Power Monitoring (EU Type) | Sonoff S60ZBTPG
Zigbee Smart Plug with Power Monitoring (EU Type) | Sonoff S60ZBTPG
تعذر تحميل توفر الاستلام
Sonoff S60ZBTPG — Zigbee Smart Plug with Power Monitoring (EU Type)
Product Description
The Sonoff S60ZBTPG is a Zigbee smart socket designed to control and monitor electrical appliances remotely while providing real-time power consumption data. It works through a Zigbee gateway and integrates seamlessly with smart home platforms for automation, scheduling, and energy management.
✅ Verified Key Features
◆ Zigbee 3.0 Protocol — Stable, low-power communication through a Zigbee coordinator
◆ Smart On/Off Control — Turn appliances on or off remotely via supported smart home apps
◆ Power Monitoring — Displays real-time voltage, current, and power consumption
◆ Energy Usage History — Tracks energy usage over time for cost and efficiency monitoring
◆ 16A High Load Capacity — Suitable for high-power devices such as heaters, kettles, water boilers, and washing machines
◆ Overload Protection — Automatically cuts power when load exceeds safe limits
◆ Schedule & Timer Support — Set on/off schedules, countdowns, and automation rules
◆ Zigbee Mesh Repeater — Acts as a Zigbee router to extend network coverage
◆ Manual Control Button — Physical button for local on/off operation
◆ Status Memory — Restores last power state after power failure
📊 Verified Technical Specifications
| Specification | Details |
|---|---|
| Model | Sonoff S60ZBTPG |
| Device Type | Zigbee Smart Plug |
| Protocol | Zigbee 3.0 |
| RF Support | ❌ No RF (433 MHz not supported) |
| Rated Voltage | AC 220–240 V |
| Maximum Current | 16 A |
| Maximum Load | Up to 3680 W |
| Power Monitoring | Voltage / Current / Power / Energy |
| Button | Physical on/off button |
| Indicator | LED status indicator |
| Plug Type | EU Type (Schuko) |
| Gateway Required | ✅ Yes (Zigbee Hub required) |
| App Support | eWeLink via Zigbee gateway |
| Voice Control | Alexa / Google Assistant (via gateway) |
| Operating Temperature | 0 °C to +40 °C |
| Housing Material | Flame-retardant PC |
| Use Location | Indoor use only |
🧠 Smart Home Integration (Verified)
◆ Works with Zigbee gateways that support Sonoff devices
◆ Compatible with Home Assistant (ZHA / Zigbee2MQTT)
◆ Supports automation rules with sensors (motion, temperature, door sensors)
◆ Can trigger actions based on power usage thresholds
🏠 Typical Applications
◆ Electric heaters
◆ Water boilers & kettles
◆ Washing machines
◆ Refrigerators
◆ Smart energy monitoring
◆ Home automation scenes
⚠️ Important Clarifications (Verified)
◆ NOT Wi-Fi — Zigbee only
◆ NOT RF — Does not support 433 MHz
◆ Requires Zigbee Gateway — Will not work standalone
◆ Indoor use only — Not waterproof
📦 What’s in the Box
◆ 1 × Sonoff S60ZBTPG Zigbee Smart Plug
◆ User manual
⭐ Why Choose Sonoff S60ZBTPG
◆ True power monitoring at socket level
◆ Handles high-power loads safely
◆ Strengthens Zigbee mesh network
◆ Reliable automation & energy tracking
◆ Compact EU plug design
