4 Channel AcuSense DVR (Pro Series) | 8MP | Hikvision iDS-7204HUHI-M1/X
The Hikvision iDS-7204HUHI-M1/X is a 4-channel AcuSense DVR in a 1U case with one hard disk bay. It accepts HDTVI, AHD, HDCVI, CVBS and IP cameras, takes HDTVI and HDCVI cameras up to 8 MP, and records with H.265 Pro+ compression. AcuSense deep learning sorts motion into people and vehicles, and AcuSearch helps you find recorded events quickly.
5-in-1 inputs: Each of the 4 BNC inputs adapts to HDTVI, AHD, HDCVI or CVBS cameras. HDTVI and HDCVI cameras are accepted up to 8 MP (3840 × 2160), and AHD cameras up to 5 MP, so you can mix old and new analog cameras on one recorder.
Up to 8 MP recording: Encoding reaches 8 MP at 8 fps on channel 1, 8 MP Lite at 15 fps on channels 2 to 4, 3K or 5 MP at 12 fps and 4 MP at 15 fps. 1080p and lower resolutions record at 25 fps (PAL) / 30 fps (NTSC).
IP cameras too: Two IP cameras can be added (up to 6 channels), each up to 8 MP. With IP enhanced mode on, the recorder takes 4 IP channels (up to 8), each up to 4 Mbps.
Motion Detection 2.0 and AcuSearch: Deep learning classifies people and vehicles, which reduces false alarms from leaves, lights and similar movement. AcuSearch works on up to 4 channels, so you can search recordings by target instead of watching hours of video.
Facial recognition or perimeter protection: The recorder supports 2-channel facial recognition (face picture comparison alarm for HD analog cameras, up to 16 face libraries) or perimeter protection on up to 4 channels with human and vehicle analysis.
Storage and outputs: One SATA bay takes a disk of up to 12 TB. HDMI output goes up to 2K (2560 × 1440) and VGA up to 1920 × 1080, with simultaneous HDMI/VGA output.
Who it's for / Works with
Analog Turbo HD (HDTVI), AHD, HDCVI and CVBS cameras, plus IP cameras on the same recorder. Remote viewing works through Hik-Connect and DDNS, and the network protocols include ONVIF.
Good to know
- The hard disk is not included.
- 8 MP at 8 fps is available on channel 1 only; channels 2 to 4 record 8 MP Lite.
- AHD cameras are supported up to 5 MP (not 8 MP).
- The network port is 10/100 Mbps.
Technical Specifications
| Model | iDS-7204HUHI-M1/X |
| Analog video input | 4-ch, BNC (1.0 Vp-p, 75 Ω) |
| Signal types | HDTVI / AHD / HDCVI / CVBS / IP |
| HDTVI input | Up to 8 MP (3840 × 2160) @ 12/15 fps |
| AHD input | Up to 5 MP (2560 × 1944) @ 20 fps |
| HDCVI input | Up to 8 MP (3840 × 2160) @ 12/15 fps |
| IP video input | 2-ch (up to 6-ch), up to 8 MP; IP enhanced mode: 4-ch (up to 8-ch), each up to 4 Mbps |
| Encoding | 8 MP @ 8 fps (channel 1), 8 MP Lite @ 15 fps (channels 2–4), 3K/5 MP @ 12 fps, 4 MP @ 15 fps |
| Video compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Smart functions | Motion Detection 2.0, 2-ch facial recognition or 4-ch perimeter protection, 4-ch AcuSearch |
| HDMI output | Up to 2560 × 1440 / 60 Hz |
| VGA output | Up to 1920 × 1080 / 60 Hz |
| Audio | 1 RCA input + 4-ch via coaxial cable, 1 RCA output, two-way audio |
| Hard disk | 1 SATA, up to 12 TB |
| Network | 1 × RJ45 10/100 Mbps |
| Remote connections | 32 |
| USB | 1 × USB 2.0 (front), 1 × USB 3.0 (rear) |
| Power supply | 12 VDC, 1.5 A |
| Power consumption | ≤ 10 W (without HDD) |
| Dimensions | 319 × 235 × 48 mm |
| Weight | ≤ 1.16 kg |
| Working temperature | -10 °C to 55 °C |
📄 Datasheet: Download the official Hikvision iDS-7204HUHI-M1/X datasheet (PDF)
